SCOTT Addict 30 Bike

Model : 265354

Key Features

  • Addict MF Carbon Frame
  • Addict MF Fork
  • Shimano Tiagra 20 Speed
  • Syncros Race 24V Wheels
  • Syncros Carbon/Alloy Parts
Find a dealer
SPECIFICATIONS
  • The all NEW SCOTT Addict 30 was redesigned from the ground up with those longer days in mind. With new geometry that is less focused on racing and more on enduring, the Addict 30 will be your go to when you're looking to put the miles in, but at a fraction of the cost.

    Bike category 1
    Road racing and triathlon bikes as well as time trial machines
    Please check the Bike Manual Section for more information
  • Frame

    Addict MF Carbon technology
    Endurance geometry / Replaceable Dropout
  • Fork

    Addict MF
    1 1/8" - 1 1/4" Carbon steerer
    Alloy Dropout
  • Headset

    Syncros Integrated
  • Rear Derailleur

    Shimano Tiagra Black RD-4700-GS
    20 Speed
  • Front Derailleur

    Shimano Tiagra FD-4700
  • Shifters

    Shimano Tiagra ST-4700
    Dual control 20 Speed
  • Brakes

    Tektro SCBR-525
    Catridge Pads
  • Crankset

    Shimano Tiagra FC-4700 Compact
    Hyperdrive 50x34 T
  • BB-Set

    Shimano BB-RS500-PB
  • Handlebar

    Syncros Creston 2.0 Compact
    Alloy 31.8mm
  • H'stem

    Syncros RR2.0
    1 1/8" / four Bolt 31.8mm
  • Seatpost

    Syncros Carbon RR1.2
    27.2/350mm
  • Seat

    Syncros FL2.0
  • Hub (Front)

    Formula Race 22 24 H
  • Hub (Rear)

    Formula Race 22 28 H
  • Chain

    KMC X10
  • Cassette

    Shimano CS-HG500
    10 Speed 11-32
  • Spokes

    14G Stainless Black 2mm
  • Rims

    Syncros Race 24V
    Front 24 / 28 Rear
  • Tires

    Schwalbe Durano Fold
    700x28C
  • Approx weights in KG

    8.50
  • Approx weights in LBS

    18.74
Use
product.useRadarChart.notAvailable
Geometry
Geometry of SCOTT Addict 30 Bike
XXS/47 XS/49 S/52 M/54 L/56 XL/58 XXL/61
A head tube angle 70.5 ° 71.0 ° 72.0 ° 72.5 ° 73.0 ° 73.3 ° 73.3 °
B head tube length 115.0 mm 4.5 in 125.0 mm 4.9 in 145.0 mm 5.7 in 165.0 mm 6.5 in 185.0 mm 7.3 in 205.0 mm 8.1 in 225.0 mm 8.9 in
C top tube horizontal 505.0 mm 19.9 in 515.0 mm 20.3 in 530.0 mm 20.9 in 545.0 mm 21.5 in 560.0 mm 22.0 in 575.0 mm 22.6 in 590.0 mm 23.2 in
D standover height 725.3 mm 28.6 in 741.1 mm 29.2 in 767.5 mm 30.2 in 787.5 mm 31.0 in 807.5 mm 31.8 in 827.1 mm 32.6 in 851.4 mm 33.5 in
E BB offset -67.0 mm -2.6 in -67.0 mm -2.6 in -67.0 mm -2.6 in -67.0 mm -2.6 in -67.0 mm -2.6 in -67.0 mm -2.6 in -67.0 mm -2.6 in
F BB height 280.2 mm 11.0 in 280.2 mm 11.0 in 280.2 mm 11.0 in 280.2 mm 11.0 in 280.2 mm 11.0 in 280.2 mm 11.0 in 280.2 mm 11.0 in
G wheel base 973.1 mm 38.3 in 979.4 mm 38.6 in 981.2 mm 38.6 in 986.8 mm 38.9 in 991.6 mm 39.0 in 999.0 mm 39.3 in 1,012.7 mm 39.9 in
H BB center to toptube center 410.0 mm 16.1 in 430.0 mm 16.9 in 460.0 mm 18.1 in 480.0 mm 18.9 in 500.0 mm 19.7 in 520.0 mm 20.5 in 550.0 mm 21.7 in
I BB center to top of seattube 470.0 mm 18.5 in 490.0 mm 19.3 in 520.0 mm 20.5 in 540.0 mm 21.3 in 560.0 mm 22.0 in 580.0 mm 22.8 in 610.0 mm 24.0 in
J seat angle 75.0 ° 75.0 ° 74.5 ° 74.0 ° 73.5 ° 73.1 ° 73.0 °
K chainstay 410.0 mm 16.1 in 410.0 mm 16.1 in 410.0 mm 16.1 in 410.0 mm 16.1 in 410.0 mm 16.1 in 410.0 mm 16.1 in 410.0 mm 16.1 in
L reach 366.6 mm 14.4 in 373.5 mm 14.7 in 377.3 mm 14.9 in 381.2 mm 15.0 in 384.6 mm 15.1 in 389.0 mm 15.3 in 397.0 mm 15.6 in
M stack 516.7 mm 20.3 in 527.9 mm 20.8 in 550.5 mm 21.7 in 571.3 mm 22.5 in 592.3 mm 23.3 in 612.5 mm 24.1 in 613.6 mm 24.2 in
N stem length
