SCOTT Addict Gravel 30 Bike

Model : 269904

Key Features

  • Addict Gravel Disc HMF Carbon Frame
  • Addict Gravel Disc HMF Fork
  • Syncros RP2.0 Disc Wheels
Find a dealer
SPECIFICATIONS
  • The SCOTT Addict Gravel 30 Disc has been set up to allow you to ride any road, anywhere and in any weather conditions. A lightweight HMF Carbon fiber frame, Syncros components, some rugged Schwalbe G-One tires and Shimano Hydraulic disc brakes give you a rig that will let you get your adventure on, but at a fraction of the cost. Find yourself, get lost.

    bike category 2.3
    Cyclo-cross bikes
    Please check the Bike Manual Section for more information

  • Frame

    Addict Gravel Disc HMF / IMP Carbon technology
    Gravel Race geometry / Replaceable Dropout
  • Fork

    Addict Gravel Disc HMF Flatmount
    1 1/8"-1 1/4" tapered Carbon steerer
    Alloy Dropout
  • Headset

    Syncros Integrated
  • Rear Derailleur

    Shimano 105 Black RD-R7000-GS
    22 Speed
  • Front Derailleur

    Shimano 105 Black FD-R7000
  • Shifters

    Shimano ST-R7020 Disc
    Dual control
    22 Speed
  • Brakes

    Shimano BR-R7070 Hyd Disc
    160/F and 160/Rmm SM-RT70 CL Rotor
  • Crankset

    Shimano 105 FC-R7000 Black
    Hyperdrive 50x34 T
  • BB-Set

    Shimano BB-RS500-PB
  • Handlebar

    Syncros Creston 2.0 Flare
    Alloy 31.8mm
  • H'stem

    Syncros RR2.0 1 1/8" / four Bolt 31.8mm
  • Seatpost

    Syncros R1.2 Carbon/AL 27.2mm
  • Seat

    Syncros Tofino T-Cutout 2.0
  • Wheelset

    Syncros RP2.0 Disc
    Syncros RWS
  • Chain

    Shimano CN-HG601-11
  • Cassette

    Shimano CS-HG700
    11-34
  • Tires

    Schwalbe G-ONE Allround FOLD
    700x35C
  • Approx weights in KG

    8.66
  • Approx weights in LBS

    19.09
  • System Weight

    120
Use
product.useRadarChart.notAvailable
Geometry
Geometry of SCOTT Addict Gravel 30 Bike
XS/49 S/52 M/54 L/56 XL/58
A head tube angle 70.0 ° 70.0 ° 71.0 ° 71.0 ° 71.0 °
B head tube length 95.0 mm 3.7 in 120.0 mm 4.7 in 140.0 mm 5.5 in 160.0 mm 6.3 in 180.0 mm 7.1 in
C top tube horizontal 505.0 mm 19.9 in 525.0 mm 20.7 in 545.0 mm 21.5 in 568.0 mm 22.4 in 590.0 mm 23.2 in
D standover height 749.8 mm 29.5 in 775.7 mm 30.5 in 796.2 mm 31.3 in 814.1 mm 32.1 in 832.0 mm 32.8 in
E BB offset -68.0 mm -2.7 in -68.0 mm -2.7 in -68.0 mm -2.7 in -68.0 mm -2.7 in -68.0 mm -2.7 in
F BB height 281.0 mm 11.1 in 281.0 mm 11.1 in 281.0 mm 11.1 in 281.0 mm 11.1 in 281.0 mm 11.1 in
G wheel base 984.0 mm 38.7 in 1,002.0 mm 39.4 in 1,017.0 mm 40.0 in 1,043.0 mm 41.1 in 1,056.0 mm 41.6 in
H BB center to toptube center 431.5 mm 17.0 in 462.7 mm 18.2 in 483.0 mm 19.0 in 503.2 mm 19.8 in 523.3 mm 20.6 in
I BB center to top of seattube 490.0 mm 19.3 in 520.0 mm 20.5 in 540.0 mm 21.3 in 560.0 mm 22.0 in 580.0 mm 22.8 in
J seat angle 74.5 ° 74.0 ° 73.5 ° 73.0 ° 73.0 °
K chainstay 422.0 mm 16.6 in 422.0 mm 16.6 in 422.0 mm 16.6 in 422.0 mm 16.6 in 422.0 mm 16.6 in
L reach 360.0 mm 14.2 in 369.0 mm 14.5 in 378.0 mm 14.9 in 390.0 mm 15.4 in 405.0 mm 15.9 in
M stack 521.8 mm 20.5 in 545.5 mm 21.5 in 564.4 mm 22.2 in 583.3 mm 23.0 in 602.2 mm 23.7 in
N stem length 90.0 mm 3.5 in 100.0 mm 3.9 in 110.0 mm 4.3 in 120.0 mm 4.7 in 120.0 mm 4.7 in
0 trail
