SCOTT Scale 700 Bike

Model : 270247

Key Features

  • Scale 27.5" Alloy 6061 / Tapered HT
  • Tapered steerer, remote Lockout
  • Syncros Rims
  • Syncros Parts
Find a dealer
SPECIFICATIONS
  • The Scale 700 will be the first race-focussed hardtail of the rest of your life. A alloy frame, a Sram Eagle Drivetrain and Syncros components combine to give you a rocket ship of a race bike!

    bike category 3
    Cross-country, marathon and hardtail bikes
    Please check the Bike Manual Section for more information

  • Frame

    Scale 27.5" Alloy 6061 Custom Butted Tubing
    QR 5x135mm / Tapered HT / BB92
    Internal Cable Routing / replaceable hanger
  • Fork

    RockShox Recon RL Solo Air
    2-Modes / Tapered Steerer
    Reb. Adj. / Lockout / 100mm travel
  • Remote System

    SCOTT RideLoc Remote
  • Headset

    Syncros Comp Press Fit / Tapered 1.5"-1 1/8"
    OD 50/61mm / ID 44/55mm
  • Rear Derailleur

    SRAM NX / Eagle 12 Speed
  • Shifters

    SRAM NX Eagle Trigger
  • Brakes

    Shimano MT400 Disc
    180/F and 160/R mm SM-RT30 CL Rotor
  • Crankset

    SRAM NX Eagle DUB
    30T
  • BB-Set

    SRAM DUB PF integrated / shell 41x92mm
  • Handlebar

    Syncros T-Bar / Alloy 6061
    T shape Flat / 9° / 680mm
  • H'stem

    Syncros 6061 Alloy
    oversized 31.8mm / 1 1/8" / 6° angle
  • Pedals

    Wellgo M-21
  • Seatpost

    Syncros / 31.6x400mm
  • Seat

    Syncros XR2.5
  • Hub (Front)

    Formula CL51
  • Hub (Rear)

    Shimano FH-RM35 CL / QR
  • Chain

    SRAM CN NX Eagle
  • Cassette

    SRAM NX / XG1230 / 11-50 T
  • Spokes

    Stainless Black 15G / 1.8mm
  • Rims

    Syncros / Disc / 32H
  • Tires

    Maxxis Ikon / 27.5x2.35" / 60TPI / EXO / TR
  • Approx weights in KG

    12.40
  • Approx weights in LBS

    27.34
  • System Weight

    128
Use
product.useRadarChart.notAvailable
Geometry
Geometry of SCOTT Scale 700 Bike
EN FR DE IT
A head tube angle angle tube de direction Steuerwinkel angolo sterzo 69.5 ° 69.5 °
B head tube length hauteur tube de direction Steuerrohrlänge lunghezza tubo sterzo 100.0 mm 100.0 mm
C top tube horizontal longueur horizontale tube supérieur Horizontale Oberrohrlänge lunghezza tubo orizzontale virtuale 575.0 mm 600.0 mm
D standover height hauteur entre-jambes Standover height altezza standover 748.0 mm 776.0 mm
E BB offset exccentrage axe de pédalier Tretlager Offset offset movimento centrale -58.0 mm -58.0 mm
F BB height hauteur axe de pédalier Tretlagerhöhe altezza movimento centrale 312.0 mm 312.0 mm
G wheel base entraxe roues Radstand passi 1,092.1 mm 1,118.0 mm
H BB center to toptube center dist. boitier - milieu tube supérieur Abst. Tretlager - Oberrohr Mit. da centro movimento centrale a centro tubo superiore
I BB center to top of seattube dist. boitier - sommet tube de selle Abst. Tretlager - Sitzrohr Oberkante da centro movimento centrale a parte superiore canotto sella 390.0 mm 440.0 mm
J seat angle angle tube de selle Sitzrohrwinkel angolo sella 73.6 ° 73.6 °
K chainstay longueur bases Kettenstrebenlänge parte inferiore carro 440.0 mm 440.0 mm
L reach reach reach lunghezza tubo orizzontale-piantone dritto virtuale 396.8 mm 421.8 mm
M stack stack stack altezza parte superiore sterzo 605.3 mm 605.3 mm
N stem length longueur potence Vorbaulänge lunghezza attacco manubrio
A head tube angle angle tube de direction Steuerwinkel angolo sterzo 69.5 ° 69.5 °
B head tube length hauteur tube de direction Steuerrohrlänge lunghezza tubo sterzo 3.9 in 3.9 in
C top tube horizontal longueur horizontale tube supérieur Horizontale Oberrohrlänge lunghezza tubo orizzontale virtuale 22.6 in 23.6 in
D standover height hauteur entre-jambes Standover height altezza standover 29.4 in 30.6 in
E BB offset exccentrage axe de pédalier Tretlager Offset offset movimento centrale -2.3 in -2.3 in
F BB height hauteur axe de pédalier Tretlagerhöhe altezza movimento centrale 12.3 in 12.3 in
G wheel base entraxe roues Radstand passi 43.0 in 44.0 in
H BB center to toptube center dist. boitier - milieu tube supérieur Abst. Tretlager - Oberrohr Mit. da centro movimento centrale a centro tubo superiore
I BB center to top of seattube dist. boitier - sommet tube de selle Abst. Tretlager - Sitzrohr Oberkante da centro movimento centrale a parte superiore canotto sella 15.4 in 17.3 in
J seat angle angle tube de selle Sitzrohrwinkel angolo sella 73.6 ° 73.6 °
K chainstay longueur bases Kettenstrebenlänge parte inferiore carro 17.3 in 17.3 in
L reach reach reach lunghezza tubo orizzontale-piantone dritto virtuale 15.6 in 16.6 in
M stack stack stack altezza parte superiore sterzo 23.8 in 23.8 in
N stem length longueur potence Vorbaulänge lunghezza attacco manubrio
