SCOTT Axis FS 20 Bike
Artikel : 423312
Key Features
- Telaio in lega di alluminio Axis FS eRIDE
- Sistema motore Bosch CX, PT600 SmartSystem
- Anteriore: Forcella Rock Shox Psylo da 140 mm specifica per e-bike
- Posteriore: Ammortizzatore X-Fusion Nude, forcella ammortizzata da 140 mm
- Cambio Shimano Deore 12 velocità
- Freni a disco Shimano
- Luci anteriori e posteriori Lezyne
- Portapacchi Racktime SnapIt 2.0 15 kg
- Parafanghi in lega Curana, luci anteriore e posteriore Lezyne
- Portapacchi Racktime SnapIt 2.0 15 kg
1. Farbe : shark grey
2. Größe
CHF 6’199.00
BLEIBEN SIE AUF DEM LAUFENDEN
Wenn Sie uns Ihre E-Mail Adresse hinterlassen, informieren wir Sie, wenn Ihr Produkt SCOTT Axis FS 20 Bike in Größe S wieder verfügbar ist.
Sie erhalten nur eine E-Mail
Lieferung in 3 - 5 Werktagen
Kostenloser Versand ab einem Bestellwert von CHF 149.00
Gratis Rücksendung innerhalb von 14 Tagen
-
Esplora nuovi posti. La Axis FS eRIDE è la e-bike adventure biammortizzata definitiva. Ultra-capace e confortevole sui terreni accidentati, ma anche adatta per andare a fare la spesa. È dotata dell’ultimissima unità motrice Bosch Performance CX e di una batteria da 800 Wh.
Con la Axis FS la tua immaginazione è l’unico limite!
Notare che le specifiche della bici sono soggette a cambiamenti senza alcun preavviso.
Nutzungsbedingung 3 -
Telaio
Alloy S-XL=29"
Integrated Suspension Technology
Virtual 4 Link kinematic, Adjustable head angle
Syncros Cable Integration System
Bosch Smart System, UDH Interface, 12x148mm with 55mm Chainline, Bosch PowerMore Ready -
Escursione
Front: 140mm, Rear: 140mm -
Forcella
RockShox Psylo Silver RC Solo Air, E-Bike, Remote Motion Control Damper 2P, QR Axle 15x110mm axle
44mm offset, tapered steerer, 140mm travel -
Ammortizzatore posteriore
X-Fusion Nude RLX Trunnion 185x47
5mm, 2P, Remote Ready, 140mm Travel
-
comando remoto
SCOTT TwinLoc Remote 2P -
Motore
Bosch Performance CX, EU: 25kmh -
Batteria
PowerTube 800Wh -
Schermo
Bosch System Controller
Intuvia 100
Mini remote -
Caricatore
2A Charger -
Deragliatore posteriore
Shimano Deore RD M6100SGS 12 Speed -
Deragliatore anteriore
SCOTT Chainguide -
Leve del cambio
Shimano Deore SL-M6100RA -
Guarnitura
FSA CK-745 165mm -
Corona
FSA 36T w/Chain Guard -
Catena
KMC E12S -
Cassetta
Shimano CS-M6100-12 10-51T -
Freni
Shimano BR-MT520 4 Piston Disc Brakes -
Disco del freno
Front: SM-RT64 CL 203mm, Rear: SM-RT64 CL 203mm -
Manubrio
Syncros Welded Alloy Combo 680mm, Backsweep 9°, Upsweep 8°, 70mm, with front Light mount and Intuvia 100 mount -
Reggisella
Syncros Duncan Dropper Post 2.5
31.6mm, S&M 361mm, L&XL 403mm -
Sella
Syncros Tofino E 2.0 -
Serie sterzo
Syncros - Acros Angle adjust & Cable Routing HS System
Stainless, +-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB -
Mozzo anteriore
Formula CL-811, 15x110mm -
Mozzo posteriore
Formula CL-148M, Boost 12x148mm -
Raggi
Sapim double butted -
Cerchio
Syncros MD30, 32H, 30mm, Pin Joint
Tubeless ready -
Gomma anteriore
Schwalbe Advancer 60-622 Wired -
Gomma posteriore
Schwalbe Advancer 60-622 Wired -
Luci
Lezyne Fusion E550SM front light
Rear Lezyne Superbright -
Portapacchi
Racktime SnapIt 2.0 15KG -
PEDALI
VP VPE-506 -
Extra
Curana alloy profile Fender
Ursus Kickstand -
Peso in kg (approx.)
28.8 -
Peso in lbs (approx.)
63.49 -
Peso totale
130kg
Il peso totale include la bici, il ciclista, l'equipaggiamento, e potenzialmente bagagli aggiuntivi
AXIS FS FRAME
The Axis FS features the same frame as the alloy version of the Patron eRide, one of our highest end eMTB’s. Subjected to the highest degree of testing and numerous iterations in the development phase, Axis FS exhibits the perfect blend of stiffness, strength and weight distribution resulting in an unmatched ride feel.
INTEGRATED SUSPENSION TECHNOLOGY
The Axis FS’s rear suspension is integrated into the frame. Not only does this give the bike a clean look, but it also has allowed us to achieve desired shock characteristics while granting us the space to strategically position elements such as the motor, the battery and a water bottle. Riding a range of varied terrain? The TracLoc remote on the handlebar alters suspension characteristics with just a touch of the thumb allowing you to adapt your suspension whenever you need it.
BOSCH E-BIKE SYSTEM
Reliability is key when it comes to e-Bike systems and Bosch is among the leaders. With the new Performance CX drive unit of 85 Nm, paired with the powerful, integrated PowerTube 800 WH battery, you can simply enjoy your ride. And if that’s still not enough, the e-bike is compatible with the Bosch PowerMore 250 range extender.
140MM TRAVEL AND DROPPER SEAT-POST
The Axis FS is a versatile e-bike, with the capability to go on trails.
Equipped with a 140mm front and rear travel, a dropper post to raise and lower your saddle more easily, and mtb tires, your ride is guaranteed to be a comfortable one both on the trail and in the city.
REAR RACK, FENDERS, AND POWERFUL LIGHTS
The Axis FS is equipped with all the features you need from your everyday companion, whether on trails or for grocery shopping. Strong Curana alloy fenders prevent you from getting dirty, powerful front and rear lights that allow you to see and be seen, a rear- rack compatible with SNAP IT 2.0 that supports up to 15kg.
