SCOTT Contessa Active eRIDE 930 Bike
Model : 290610
Key Features
- Contessa Active eRIDE Alloy Frame
- SR Suntour 120mm Fork
- Shimano Deore 9 Speed
- Active Plus up to 1000Wh, PowerTube
- Shimano Disc Brakes
1. Size
SPECIFICATIONS
-
The SCOTT Contessa Active eRIDE 930 features proven electric assist technology in a comfortable off-road mountain bike package. It has a low standover height combined with women's specific contact points, and powered by a Bosch motor, the Contessa Active eRIDE will give you hours of trail riding energy.
Please note that bike specifications are subject to change without prior notice -
Frame
Alloy frame
Bended TT
Tapered Headtube E2
Custom butted tubing / internal cable routing
Bosch Gen3 / Integr. removable Battery / Boost 148x12mm
DO Kickstand mount / Range Booster Ready -
Travel
120mm -
Fork
SR Suntour XCM34 Coil
15x110mm QR axle / Tapered Steerer
Remote Lockout / 120mm travel -
Remote System
SR Suntour Remote
-
Drive Unit
Bosch Active Line Plus
EU: 25kmh / INT: 20mph -
Battery
PowerTube 500Wh -
Display
Bosch Purion -
Charger
2A Charger -
Rear Derailleur
Shimano RD-M3100 / 9 Speed -
Shifters
Shimano SL-M2000 -
Crankset
FSA CK-200 / 165mm -
Chainring
FSA WB437 32T w/CG -
Chain
KMC e9S -
Cassette
Shimano CS-HG200-9 ACERA 11-36 -
Brakes
Shimano BR-MT200 Disc -
Rotor
Front: SM-RT30 CL 180mm / Rear: RT-EM300 CL 180mm -
Handlebar
Syncros 3.0 720mm / 31.8mm / 9° / 12mm rise
Syncros Women Comfort lock-on grips -
H'stem
Syncros 3.0 / 7° / Black -
Seatpost
Syncros 3.0 / 31.6mm -
Seat
Syncros Savona 2.5 V-Concept -
Headset
Syncros OE / Tapered 1.5"-1 1/8"
semi integ. OD 50/62mm / ID 44/56mm -
Hub (Front)
Shimano HB-MT400-B CL / 15x110mm -
Hub (Rear)
Shimano FH-MT400-B CL / Boost 12x148mm -
Spokes
Stainless Black -
Rims
Syncros X18 / 32H / 30mm / Pin Joint -
Front Tire
Kenda Booster 29x2.6" / 30TPI -
Rear Tire
Kenda Booster 29x2.6" / 30TPI -
Lights
Bosch Light Cable pre-installed F&R -
Approx weight in KG
24.3 -
Approx weight in LBS
53.57 -
Max. System Weight
128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
Use
No Radar Chart Available Currently
Geometry
| XS / 900 | S / 900 | M / 900 | L / 900 | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | head tube angle | 67.0 ° | 67.0 ° | 67.0 ° | 67.5 ° | ||||||||||||||
| B | head tube length | 110.0 mm | 110.0 mm | 120.0 mm | 130.0 mm | ||||||||||||||
| C | top tube horizontal | 580.0 mm | 580.0 mm | 600.0 mm | 620.0 mm | ||||||||||||||
| D | standover height | 741.0 mm | 766.0 mm | 771.0 mm | 800.0 mm | ||||||||||||||
| E | BB offset | -57.0 mm | -57.0 mm | -57.0 mm | -57.0 mm | ||||||||||||||
| F | BB height | 320.0 mm | 320.0 mm | 320.0 mm | 320.0 mm | ||||||||||||||
| G | wheel base | 1,165.2 mm | 1,165.2 mm | 1,186.4 mm | 1,201.8 mm | ||||||||||||||
| H | BB center to toptube center | ||||||||||||||||||
| I | BB center to top of seattube | 355.0 mm | 400.0 mm | 440.0 mm | 480.0 mm | ||||||||||||||
| J | seat angle | 74.0 ° | 74.0 ° | 74.0 ° | 74.0 ° | ||||||||||||||
| K | chainstay | 480.0 mm | 480.0 mm | 480.0 mm | 480.0 mm | ||||||||||||||
| L | reach | 398.6 mm | 398.6 mm | 416.0 mm | 432.6 mm | ||||||||||||||
| M | stack | 632.0 mm | 632.0 mm | 642.0 mm | 653.0 mm | ||||||||||||||
| N | stem length | ||||||||||||||||||
| 0 | trail | 114.4 mm | 114.4 mm | 114.4 mm | 110.7 mm | ||||||||||||||
